sábado, 25 de febrero de 2012

Ascensor Barón 20/ Baron Funicular 20

El trabajo de carpintería en miniatura ha comenzado.
The miniature woodworking has begun.

Lentamente la fachada va recibiendo los marcos de puertas y ventanas, molduras y forro de tablas.
The facade is slowly getting window and door frames, moldings and lining boards.
39/365

miércoles, 22 de febrero de 2012

Ascensor Barón 19/ Funicular Baron 19

No hay mucho nuevo que mostrar, más que nada ha sido tomar decisiones, diseño y un poco de trabajo en la estructura.
Not too much to show, mostly it has been taking decisions, some design and a little work on the structure.


No tengo más comentarios excepto que al ver las fotos me doy cuenta que mi taller necesita un poco de orden.
I have no further comment except that seeing the pictures I realize that my studio needs a little order.
38/365

lunes, 20 de febrero de 2012

Ascensor Barón 18/ Baron funicular 18

Un poco de trabajo en madera, los carros ya tienen techo y estoy pensando en como pintar.
A bit of woodworking, cars now have roofs and I'm thinking how to paint them.



Comencé el trabajo en la fachada de la estación superior, en este caso también habrán ciertas licencias con respecto al original ya que solo trabajo con fotos.
I started to work on the facade of the upper station, in this case I will also have certain licenses from the original because I'm working only with pictures.
37/365

viernes, 17 de febrero de 2012

Ascensor Cerro Barón 17/ Baron Hill Funicular 17

Ya logré una primera versión del programa para controlar el ascensor con el Arduino. Se inicia el movimiento con un botón y despues mediante otros dos botones se cambia automáticamente la dirección de la carrera y se detiene todo el sistema, incluyendo un periodo de espera de 10 segundos.
Now I got a first version of the program to control the elevator with the Arduino board. The movement starts with a button and then by two other buttons automatically change career direction and stops all the system, including a daley period of 10 seconds.
36/365

miércoles, 15 de febrero de 2012

Ascensor Cerro Barón 16/ Baron Hill Funicular 16

Video del ascensor en funcionamiento con el servo y controlado por el Arduino con dos botones. Ya tengo el nuevo código casi resuelto.
Video of the funicular with the servo controlled by the Arduino with two buttons. Now I have almost solved the new code.
35/365

Ascensor Barón 15/ Baron funicular 15

Después de mucho trabajo en el otro motor, engranajes y bujes tuve que usar el plan B y usar un servo con giro continuo.
After a lot of work on the other motor, gears and bushings I got to use plan B and use a continuous rotation servo.

Después de mucho trabajo en el otro motor, engranajes y bujes tuve que usar el plan B y usar un servo con giro continuo.
After a lot of work on the other motor, gears and bushings I got to use plan B and use a continuous rotation servo.

Ahora estoy trabajando en el código para que haga automáticamente un ciclo de subida y otro de bajada con un retardo de tiempo y botones sensores de final de carrera.
I'm working on the code to automatically make a cycle in one direction, stop for a while then reverse the direction and stop with limit sensors.

Para conectar el cable de retorno usé un resorte para que controle cualquier cambio de tensión en los cables de subida.
To connect the return cable I used a spring to control any changes in tension in the  main cable.
34/365

lunes, 13 de febrero de 2012

Ascensor Barón 14/ Funicular Baron 14

Así queda el huinche armado.
This is the winch assembled.

La velocidad ahora está bien pero es demasiado bullicioso así que creo que voy a seguir con el plan B y usar el servo.
Now the speed is fine but it is too noisy so I think I'll move to plan B and use the servo.
33/365

domingo, 12 de febrero de 2012

Ascensor Barón 13/ Barón Funicular 13

Ha veces hay que desarmar todo para poder sortear algún problema. Ahora rearmé todo el sistema del motor para agregarle un engranaje y reducir la velocidad del tambor del huinche. A la vez el motor quedó montado en un pivote para poder autoregular la presión sobre el engranaje sin fin.
Sometimes you have to disassemble everything to overcome any problems. Now I reset the entire motor system to add a gear to slow the winch drum. Also the motor is mounted on a pivot to self-regulate the pressure on the worm gear.


A la vez estoy preparando un huinche con un servo por si el primer sistema falla.
At the same time I am preparing a winch with a servo system in case the first fails.

Otra mejora son estas dos poleas para poner un cable de retorno. No sé si el ascensor original tiene un cable de retorno pero an mi caso va a ayudar a evitar descarrilamientos.
Another improvement are this two pulleys to put a return cable. I don't know if the original funicular has a return cable but an my case it will help to prevent  a derailment.
 32/365

viernes, 10 de febrero de 2012

Nido/ Nest

Hace unos días encontré este nido.
A few days ago I found this nest.

Debe haber sido de un zorzal ya que tiene restos de caracoles.
It must have been of a thrush as it has remains of snails.

Se nota que tomó un gran tiempo y dedicación hacerlo.
At a closer look it seems that took a great time and dedication to make.
30/365

lunes, 6 de febrero de 2012

Estereograma 2/ Stereogram 2


Dos nuevos experimentos en Stereogramas animados en GIF, hacer click en la foto para acceder a la animación.
Two new experiments in animated GIF Stereogramas, click on the picture to access the animation.



Como experimento es interesante pero es un tanto molesto el salto de imagenes, voy a probar con una distancia menor entre imágenes.
As an experiment is interesting but jumping pictures is somehowt annoying , I'll try a shorter distance between images.
29/365

domingo, 5 de febrero de 2012

Estereograma/ Stereogram

Hoy encontré este sitio de la biblioteca pública de Nueva York donde encontraron esta forma de presentar las antiguas imágenes estereoscópicas mediante un GIF animado. Las imágenes eran tomadas con una cámara de doble lente y eran vistas en un visor especial donde cada imágen quedaba frente a cada ojo.
Today I found this site of the New York Public Library where they found this way of presenting the old stereoscopic images using an animated GIF. The images were taken with a dual lens camera and were viewed in a special viewer where each image was in front of each eye.

En este caso el efecto se logra de alguna forma haciendo un rápido cambio entre una imágen y otra. Para ver el efecto es necesario hacer click en la imagen. Esta es mi primera prueba y no está bien logrado aún. El link para el sitio de la biblioteca de Nueva York es este: Stereogranimator.
In this case the effect is achieved in some way making a quick change from one image to another. To see the effect you need to click on the image. This is my first test and still not well managed. The link to the site of the library of New York is this: Stereogranimator.

28/365
